CC1 Compression Load Cell

sometimes defined as a canister load cell,high capacity compression load cell by Flintec is well known for the quality and reliability.
CC1 Compression Load Cell performs highly accurate measurements of compression forces with ease by utilising the simple mounting arrangement and the central load introduction facility.

Key Features:

• Capacities of 30Klb and 50Klb
• All stainless steel construction
• Environmental Protection IP68 with complete hermetic sealing
• Traceable calibration in accordance with NIST (National Institute of Standards and Technology)
• CC1 – mV/V output with standard 6-pin MOLEX connector

Purpose: Pump monitoring systems (POC / polished rod load cell).
